Industrial Sliding Doors

Motorised Heavy Industrial Sliding Doors are excellent for large openings and are custom built to meet the requirements of our customers. They are ideal for industrial applications, both as external and internal doors where maximum door opening is required. The doors are designed for tough everyday operation, extremely sturdy, resistant to impact and effectively corrosion-protected.

  • Doors are constructed of 100% CFC free polyurethane high density insulated steel sliding doors of 80 mm, 120 mm or 150 mm thickness with protection against corrosion or corrugated PEB cladding sheet
  • Minimum headroom required and is best suited for temperature controlled areas
  • Top rollers made of self-lubricating nylon which ensures smooth and noise free movement of the door
  • Hot galvanised material treated with primer and polyester resin offer optimum protection against adverse effects of the environment
  • The stucco embossing on both sides of the door leaf makes the surface resistant to scratches
  • Equipped with CE certified rugged and powerful drive unit, integral electronic control unit and built in contact-less magnetic limit-switch
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Industrial Sliding Doors
Door Type Conventional Sliding, Telescopic & Craneway
Applications Industrial, Residential, Commercial, Warehouse, Airport, Shipyards, Craneway or Any Entrance
Door Mounting Bottom Mounted
Maximum Clear Width 10000mm Single Leaf / 20000mm Double leaf (Bi-Parting)
Maximum Height 12000 mm (*Larger dimensions available on request)
Opening Direction Horizontal Straight
Opening Speed Up to 0.16 m/s (*Up to 0.3 m/s on request)
Closing Speed Up to 0.16 m/s (*Up to 0.3 m/s on request)
Security Features CE marked according to the European Machinery Directive 2006/42/CE &
Type tested according to EN 13241-1
Door Frame Square or Rectangular steel hollow tubular section
Cladding 0.5mm thk PPGL / PPGI Corrugated Sheet
2mm thk MS / GI / SS304 / SS316 Sheet
40mm/ 60mm / 80mm / 100mm thk Puff / Rockwool Panel with Pre-Painted Sheet on both Side
Sealing Rubber Seal on side & Brush seal on bottom
Bottom Rail C channel with round polished bar
Bottom Rollers Italian make Galvanised Wheels min 120mm dia. with ball bearings and axle with lubrication point
Full Height Column Galvanised adjustable upper guide brackets with Heavy Duty steel Box section - for crane application
Guide Rollers Heavy Duty Steel adjustable upper guide brackets with Nylon Roller

Standard Specifications

  • 230V-1ph, N / 415V-3ph, N
  • Rack driven rugged and powerful drive unit with integral electronic control unit
  • Open / Emergency Stop / Close
  • 300Kg to 25000Kg
  • Intensive use
  • Operator : IP 44 (* Higher IP rating on request)
  • Key operated
  • Pair of Photocells with anodised aluminium vertical mountings
  • Flashing light

Additional Optional Accessories

  • Pair of Reverse Safety photocells
  • Key Selector, Remote Transmitter
  • Vertical Safety Edge
  • In-Built Wicket Door with Interlocking, Vision Windows
  • Between Door & Boom Barriers or equipped with a client control unit

Standard Colours Similar To

  • Grey Primer RAL 7015
  • Blue RAL 5010
  • White RAL 9002

Optional Surface Finish

  • As Per ISO 1461:2022
  • As per ISO 12944 With Sand Blasting
*Other RAL available on request
